Philips Pocket Memo voice recorder  Digital, Slide-switch operation PCL1000 series

Philips Pocket Memo voice recorder Digital, Slide-switch operation PCL1000 series

Product Code:PCL1000

Speak. Send. Done.


SpeechLive does the rest

Philips SpeechLive takes the dictation workflow to the cloud – with all of its great benefits. Record your dictations – anywhere, at any time and benefit from maximum security and reliability. Conveniently receive written documents in no time with the first complete Philips speech-to-text workflow solution.

Description







Philips SpeechLive-Cloud Dictation Solution PCL1000 series



Highlights

Dictation microphones
  • Philips SpeechMike Air wireless dictation microphone LFH3000 series
  • Philips SpeechMike Premium USB dictation microphone LFH3500 series
  • Philips SpeechMike USB dictation microphone LFH3200 series


Transcription products

  • Philips professional transcription set LFH7277
  • Philips transcription set LFH7177, Philips foot pedal LFH2300 series
  • Philips hand control LFH2305


 Software

  • Philips SpeechExec Pro Dictate dictation software LFH4400
  • Philips SpeechExec Pro Transcribe transcription software LFH4500


FEATURES



csm pcl1000 non stop file access fim 8eccf92d7cConstant file access for working anywhere and anytime

Access all your dictation files anywhere, anytime. Even without Internet access, you can still work in local mode and synchronize all your dictation files when you are online again.









Easy set-up and local support for quick installation ans assistance

csm pcl1000 easy set up local support fim a74268e8be

Setting up SpeechLive is quick and easy. The fast and intuitive installation process ensures you are ready to go within minutes. If needed, authorized SpeechLive partners will offer local support and assistance.







csm pcl1000 web browser configuration fim 79c554b402Web browser-based workflow management for convenient administration

The workflow can conveniently be managed from your web browser. No need to install any complicated software. Settings can be re-adjusted anywhere, anytime.







Secure online storage to keep your files protected

csm pcl1000 securely stored online fim 16d2b7a4ba

SpeechLive offers highly secure online storage, keeping your files safe from unauthorized access. The solution works with maximum connection security using the HTTPS protocol. All stored data is automatically encrypted and server mirroring keeps your data reliably secured and available anytime.







csm pcl1000 double encryption fim 7bb528f130Double encryption in real time for maximum security

To avoid unauthorized access, dictation files are encrypted in real time. The highest encryption standard available is used to protect your data, even during upload and download. Files can be encrypted for a third time if recorded in the DSS Pro format for maximum security.







Backup and restore function for highest data safety

csm pcl1000 backup function fim 7dfe538c12

The automatic backup function protects your data against accidental loss. Your dictation files are always safe, even if your computer crashes, you suddenly lose Internet connection or unintentionally erase your data.





csm pcl1000 no local infrastructure required fim 5ccc9c8f38Independence from local infrastructure for increased flexibility

With SpeechLive you are ready to go – no local server infrastructure is required. Enjoy the full benefits of the solution right away, no matter if you are a one-man business or run a company with several employees. Your files are always available independent from changes to your IT environment.







Flexible sunscriptions scale the solution along with your business

csm pcl1000 speechlive grows fim 314dadbd1c

SpeechLive adapts to suit the needs of your business by giving you the opportunity to adjust the number of users at any time. SpeechLive offers flexible subscription options, making sure the solution always fits your budget requirements.





csm pcl1000 additional services fim 3be2d8b590Optional transcription service to meet all your needs

Philips SpeechScribe – the cutting-edge transcription service that now does the typing for you. Get finished documents in three easy steps. First speak, second send, third, receive the finished document. It is as easy as that and saves you valuable time, increasing the efficiency of your work life.





Optional speech recognition service for instant delivery

csm pcl1000 backup function fim 7dfe538c12

The speech recognition service allows you to get more work done, in less time. Simply dictate your notes or tasks into your Philips voice recorder or dictation recorder app and have your files transcribed almost immediately by our sophisticated software.





csm pcl1000 excellent workflow management fim 86f5eb3f13Excellent workflow management for increased efficiency

Adapt the solution to your company’s way of working. Administrators can easily define authors and typists, as well as assigning the workflow from anywhere in the world, to balance workload. With the advanced business package you can individually assign typists to each author, ensuring confidentiality and efficiency.



Part of Philips dictation solution for seamless integration

csm pcl1000 part of philips solutions fim 54b4ab4522

SpeechLive works seamlessly with Philips Pocket Memo dictation recorders, SpeechMike dictation microphones and SpeechExec dictation recorders for Smartphones. Together with SpeechExec software, SpeechLive creates a complete workflow, making speech-to-text even easier.









SPECIFICATIONS

SPECIFICATIONS

Technical Specifications



 Connectivity

Headphones: 3.5 mm

Microphone: 3.5 mm

USB: micro USB 2.0

Docking connector

Memory card slot

Display

Type: color TFT

Diagonal screen size: 2.4 inches / 6.1 cm

Resolution: 320 × 240 pixels

Storage media

Exchangeable memory card

Memory card types: SD/SDHC (DPM8000, DPM8200), micro SD/SDHC (DPM8500), up to 32 GB

Mass storage class compliant

Data transfer speed: 6.75 MB/s read speed, 5.0 MB/s write speed

 Audio recording

Recording format: DSS/DSS Pro (Digital Speech Standard), MP3, PCM

Built-in microphones: 1 directional microphone, 1 microphone for 360 degree recording

Recording modes: DSS QP (.ds2/mono), DSS SP (.dss/mono), MP3 (.mp3/stereo), PCM Voice (.wav/mono), PCM Stereo (.wav/stereo)

Bit rate: 13.7 kbit/s (DSS SP), 28 kbit/s (DSS QP), 192 kbit/s (MP3), 353 kbit/s (PCM Voice), 705 kbit/s (PCM Stereo)

Edit modes: insert (DSS/DSS Pro), overwrite (DSS/DSS Pro, MP3, PCM), append (DSS/DSS Pro, MP3, PCM)

Recording time (4 GB memory card): 700 hours (SP), 350 hours (QP), 50 hours (MP3), 27 hours (PCM Voice), 13 hours (PCM Stereo)

Sample rate: 44.1 kHz (MP3), 22.05 kHz (PCM), 16 kHz (DSS QP), 12 kHz (DSS SP)

Sound

Speaker type: built-in round, dynamic speaker

Speaker diameter: 28 mm






Acoustic frequency response: 300 – 7500 Hz

Speaker output power: > 200 mW

Power

Battery type: Philips rechargeable Li-ion battery ACC8100

Battery capacity: 1000mAh

Battery lifetime: up to 30 hours of recording (DSS Pro mode)

Standby time: more than 200 days

Charging time (full charge): 3 hours

Security

Real time file encryption

Encryption standard: Advanced Encryption Standard (AES or Rijndael Algorithm) with 256 bits

Device lock with pin code

User identification via PIN code

Number of supported user IDs: 40

Barcode scanner (DPM8500)

Compatible bar codes: UPC–A, UPC–E, EAN–8, EAN–13, Code 128, GS1–128, ISBT 128, Code 39, Interleaved 2 of 5, Inverse 1D, GS1 DataBar, Matrix 2 of 5

Scan engine: CCD-based, single line

System requirements (SpeechExec workflow software)

Processor: Intel Pentium 4, 1.0 GHz or equivalent processor

RAM memory: 1 GB (2 GB recommended)

Hard disk space: 100 MB for SpeechExec software, 850 MB (32 bit)/2 GB (64 bit) for Microsoft .NET Framework (Windows)

Operating system: Windows 8/7/Vista (32/64 bit), Mac OS X 10.10/10.9 (Mac functionality may be limeted)

Free USB port

DVD-ROM drive

Graphics card: DirectX-compliant graphics card with hardware acceleration recommended (Windows)

Windows Media Player must be installed on a Windows operating system

Green specifications



Compliant to 2011/65/EU (RoHS)

Lead-free soldered product

Operation conditions

Temperature: 5° – 45° C/41° – 113° F

Humidity: 10 % – 90 %, noncondensing

Dimensions

Product dimensions (W × D × H): 53 × 123 × 15 mm / 2.1 × 4.8 × 0.6 inches

Weight: 117 g/4.1 oz including battery and memory card

Package contents

Pocket Memo digital dictation recorder

Docking station

Memory card

Rechargeable battery

USB cable

Pouch

DVD containing software (DPM8000, DPM8200)

User manual

Available accessories

Philips rechargeable Li-ion battery ACC8100

Philips SDHC memory card LFH9004

Philips telephone pickup microphone LFH9162

Philips meeting microphone LFH9172

Philips foot pedal LFH2210

Philips WLAN adapter ACC8160

Philips SpeechExec remote device management software LFH7470

Philips SDK for dictation hardware LFH7475

VERSIONS

VERSIONS



1   DPM8000

    Slide-switch operation (record, stop, play, fast rewind)
    SpeechExec Pro Dictate workflow software







2   DPM8100

    Slide-switch operation (record, stop, play, fast rewind)









3   DPM8200

    Slide-switch operation (fast forward, record/play, stop, fast rewind)
    SpeechExec Pro Dictate workflow software









4   DPM8300

    Slide-switch operation (fast forward, record/play, stop, fast rewind)











5

   LFH3610

    Slide-switch operation with integrated barcode scanner
